Socket Weld Forged Fittings
Socket Weld Forged Fittings are high-pressure pipe fittings designed with socket connections to provide strong, reliable, and leak-proof joints. Manufactured from premium forged materials, they offer excellent strength, corrosion resistance, and durability for oil & gas, petrochemical, power plants, chemical processing, marine, and heavy industrial piping applications.
Overview
Socket Weld Forged Fittings are precision-engineered fittings used to connect pipes by inserting the pipe into a recessed socket area and applying a fillet weld. These fittings provide a strong and permanent connection suitable for high-pressure and high-temperature applications.
Manufactured using superior quality forged materials, Socket Weld Forged Fittings deliver excellent mechanical strength, dimensional accuracy, and long-lasting performance. Their design helps reduce leakage risks and ensures reliable operation in critical piping systems.
Our Socket Weld Forged Fittings are available in multiple sizes, pressure classes, material grades, and configurations to meet different industrial needs. They are widely used in refineries, chemical plants, oil & gas pipelines, power generation facilities, marine industries, and process piping systems.
1.png)
Technical Specifications
| Material | Grades Available | Standards | Size Range | Pressure Class | Types | End Finish |
|---|---|---|---|---|---|---|
| Carbon Steel Socket Weld Forged Fittings | ASTM A105, A350 LF2 | ASTM, ASME B16.11 | 1/8” – 4” | 3000#, 6000#, 9000# | Socket Weld Elbow, Tee, Coupling, Union, Cap | Socket Weld End, Black Finish |
| Stainless Steel Socket Weld Forged Fittings | SS 304/304L, 316/316L, 321, 347, 904L | ASTM A182, ASME B16.11 | 1/8” – 4” | 3000#, 6000#, 9000# | Socket Weld Tee, Elbow, Cross, Coupling | Polished, Pickled |
| Alloy Steel Socket Weld Forged Fittings | ASTM A182 F5, F9, F11, F22, F91 | ASTM A182, ASME B16.11 | 1/8” – 4” | 3000#, 6000#, 9000# | Socket Weld Elbow, Tee, Coupling, Cap | Socket Weld, Beveled Finish |
| Duplex / Super Duplex Socket Weld Fittings | UNS S31803, S32205, S32750, S32760 | ASTM A182 | 1/8” – 4” | 3000#, 6000# | Socket Weld Tee, Elbow, Coupling | Pickled & Passivated |
| Inconel Socket Weld Forged Fittings | Inconel 600, 601, 625, 718 | ASTM B564 | 1/8” – 4” | 3000#, 6000# | Socket Weld Elbow, Tee, Coupling | Polished, Pickled |
| Hastelloy Socket Weld Forged Fittings | Hastelloy C22, C276 | ASTM B564 | 1/8” – 4” | 3000#, 6000# | Socket Weld Tee, Coupling, Cap | Polished, Pickled |
| Monel Socket Weld Forged Fittings | Monel 400, K500 | ASTM B564 | 1/8” – 4” | 3000#, 6000# | Socket Weld Elbow, Tee, Coupling | Polished, Mill Finish |
| Titanium Socket Weld Forged Fittings | Titanium Gr.1, Gr.2, Gr.5 | ASTM B381 | 1/8” – 4” | 3000#, 6000# | Socket Weld Elbow, Tee, Coupling | Pickled, Polished |
Features & Advantages of Socket Weld Forged Fittings
Improves stress distribution for enhanced structural integrity.
Improves stress distribution for enhanced structural integrity.
Available in stainless steel, carbon steel, alloy steel, and duplex grades.
Ensures accurate fit and dependable sealing.
Ideal for space-constrained piping systems.
Enhances durability and mechanical performance.
Applications Across Industries
Oil & Gas
Used in upstream, midstream and downstream pipeline systems.
Petrochemical
Used in upstream, midstream and downstream pipeline systems.
Power Generation
Used in upstream, midstream and downstream pipeline systems.
Chemical Processing
Used in upstream, midstream and downstream pipeline systems.
Marine & Offshore
Used in upstream, midstream and downstream pipeline systems.
Water Treatment
Used in upstream, midstream and downstream pipeline systems.
Frequently Asked Questions
Technical questions on our Socket Weld Forged Fittings, answered by our engineering team.
Socket Weld Forged Fittings are used for creating strong welded pipe connections in high-pressure piping systems where reliability and leak prevention are required.
Common types include Socket Weld Elbow, Tee, Cross, Coupling, Union, Cap, Reducer Insert, and Boss fittings.
They are manufactured in Carbon Steel, Stainless Steel, Alloy Steel, Duplex Steel, Super Duplex Steel, Inconel, Hastelloy, Monel, Nickel Alloy, and Titanium grades.
Socket Weld Forged Fittings are manufactured according to ASME B16.11, ASTM, ANSI, and international dimensional standards.
They provide high strength, excellent leakage protection, compact design, pressure resistance, durability, and reliable performance in critical industrial piping systems.
